NEUMANN TLM 67

מיקרופון קונדנסר Neumann TLM 67 הוא החידוש העכשווי של המיקרופון האגדי Neumann U 67 עם אלקטרוניקת FET, שלושה דפוסי קליטה עם מתגי הנחתה ו- Low Cut

• Acoustic Operating Principle: Pressure Gradient Transducer
• Directional Pattern: Omnidirectional / Cardioid / Figure 8
• Frequency Range: 20Hz – 20kHz
• Sensitivity at 1kHz into 1kΩ
• Omnidirectional: 10 mV/Pa
• Cardioid: 18 mV/Pa
• Figure 8: 9 mV/Pa
• Rated Impedance: 50Ω
• Rated Load Impedance: 1kΩ
• Equivalent Noise Level, CCIR
• Omnidirectional: 29 dB
• Cardioid: 24 dB
• Figure 8: 30 dB
• Equivalent Noise Level, A-Weighted
• Omnidirectional: 16 dB-A
• Cardioid: 11 dB-A
• Figure 8: 17 dB-A
• Signal-To-Noise Ratio, CCIR
• Omnidirectional: 65 dB
• Cardioid: 70 dB
• Figure 8: 64 dB
• Signal-To-Noise Ratio, A-Weighted
• Omnidirectional: 78 dB-A
• Cardioid: 83 dB-A
• Figure 8: 77 dB-A
• Maximum SPL for THD
• Omnidirectional: 110 dB
• Cardioid: 105 dB
• Figure 8: 111 dB
• Maximum SPL for THD
• Omnidirectional: 130 dB
• Cardioid: 125 dB
• Figure 8: 131 dB
• Maximum Output Voltage: -1 dBu
• Power Supply: P48
• Matching Connector: XLR 3F
• Weight: 490 g
• Dimensions
• Diameter: 56 mm
• Length: 200 mm
